ABLIC S-82F9/82D9 Battery Monitoring ICs

ABLIC S-82F9/82D9 Battery Monitoring ICs are high-voltage battery monitoring ICs developed using CMOS technology. These ICs operate at a 3.6V to 24V voltage range and support 7.5V to 21.5V (±1%) voltage detection accuracy. The S-82D9 and S-82F9 battery monitoring ICs are capable of confirming the voltage in stages since these ICs detect four and five voltage values, respectively. These ICs include an EN (Enable) pin that allows external control to shut down the IC and reduce current consumption during standby or low-power modes. The S-82F9/82D9 battery monitoring ICs are ideal for rechargeable lithium-ion battery packs, cordless power tools, e-bikes, and cordless cleaners.
