Intel NUC6C嵌入式主板套件

Intel® NUC6C嵌入式主板套件采用Intel Celeron®  J3455处理器，并具有高达10W热设计功率 (TPD) 平均功率。NUC6C套件设有32Gb板载存储，支持1.35V低压JEDEC内存。这些NUC6C套件支持DDR3L 1600MHz或1866MHz SO-DIMM、非ECC（纠错码）内存以及1600MHz或1866MHz的内存速度。该主板通过处理器支持HDMI和视频图形阵列 (VGA) 集成显卡。HDMI端口支持标准视频、增强视频或高清视频，并支持多声道。这些NUC6C嵌入式主板套件的工作温度范围为0ºC至 50ºC。 特性包括VGA排针、通过HDMI v2.0接口实现的高清音频、外设接口、高达433Mbps的最大传输速度以及Intel®平台可信技术。

特性

  • Processor
    • Soldered-down quad-core Intel® Celeron® processor J3455 with up to 10W Thermal Design Power (TDP)
    • Intel HD Graphics 500
    • Integrated memory controller
  • Memory
    • Support for DDR3L 1600 or 1866MHz SO-DIMMs
    • Support for 4Gb and 8Gb memory technology
    • 2GByte DDR3L 1600MHz SO-DIMM pre-installed
  • USB 3.0 and USB 2.0 ports peripheral interfaces
  • Storage
    • One SATA 6Gb/s port (black), one full-sized SDXC slot, and 32Gb embedded multimedia card
  • Operating System
    • Supports Microsoft* Windows* 10 Home and Microsoft* Windows* 10 Pro
    • Intel NUC kit NUC6CAYS comes with Windows 10 Home pre-installed on the eMMC storage device
  • LAN Support
    • Gigabit (10 or 100 or 1000Mb/s) LAN subsystem using the Realtek* 8111HN Gigabit Ethernet Controller

规范

  • 10W Thermal power design average power
  • 0ºC to 50ºC temperate range
  • 4 inches by 4 inches form factor
  • Supports 1.35V low voltage memory
  • 8GByte (maximum) total system memory
  • 1920 x 1200 @ 60Hz graphics resolution
  • 3A (maximum) current rating
  • 12V to 19V DC input voltage

NUC6C Board Block Diagram

Intel NUC6C嵌入式主板套件
