Apacer Technology Inc. SV24P-25 Serial ATA Flash Drives

Apacer Technology Inc. SV24P-25 Serial ATA Flash Drives are well-balanced SSD drives utilizing 3D-NAND for higher capacity up to 1920GB, providing more power efficiency than 2D-NAND. These flash drives are built with a powerful SATA controller supporting on-the-module ECC and an efficient wear-leveling scheme. The SV24P-25 flash drives feature Advanced Encryption Standard (AES) for data safeguarding. End-to-End data protection ensures that data integrity is assured at multiple points in the path to enable reliable delivery of data transfers, especially for highly-intensive applications. These flash drives consume 485mA power in active mode and 65mA in idle mode.

The SV24P-25 serial ATA flash drives feature a 5V±10% supply voltage and operate within a -40°C to 85°C wide temperature range. These flash drives incorporate the page mapping file translation layer and offer various implementations, including power saving modes, wear leveling, S.M.A.R.T., overprovisioning, DataRAID^™, and SMART Read Refresh^™.

Features

Compliance with SATA Revision 3.2:
- SATA 6Gb/s interface
- Backward compatible with SATA 1.5Gb/s and 3Gb/s interfaces
- ATA command set-4 (ACS-4)
120GB, 240GB, 480GB, 960GB, and 1920GB capacities
DRAM cache for enhanced random performance
SATA power management modes
>3,000,000 hours MTBF
Performance:
- 600MB/sec burst read/write
- Up to 560MB/sec sequential read
- Up to 495MB/sec sequential write
- Up to 96,000IOPS random read (4K)
- Up to 84,000IOPS random write (4K)
RoHS compliant

Flash management:
- Low-Density Parity-Check (LDPC) code
- Global wear leveling
- Flash bad-block management
- Flash translation layer - page mapping
- S.M.A.R.T.
- Device sleep
- ATA secure erase
- TRIM
- Hyper cache technology
- Over-provisioning
- DataRAID^™
- SMART Read Refresh^™

Specifications

Temperature range:
- Operating:
  - 0°C to 70°C standard
  - -40°C to 85°C wide
- -55°C to 100°C storage
Power consumption:
- 485mA in active mode
- 65mA in idle mode

Connector type:
- 7-pin SATA signal connector
- 15-pin SATA power connector
Form factor:
- 2.5”
- 100mm x 69.85mm x 6.90mm dimensions
- 69.38g±5% net weight
