ethernet cable

What's the significance of PoE?

an animation of lightning bolts on the right, and binary code on the left with an ethernet cord in the center

1 cable = 2 functions
(power + network or data)

an animation of a Power cord coming in from the bottom left with a cord cut to denote that this is power cordless technology

Can power devices without power supply

an animation denoting edge computing technology

More power & faster speeds with edge computing

PoE design advantages

Ease of installation

Cost reduction

Greater flexibility/scalability

Higher efficiency

Increased reliability

Improved safety

Remote management

PoE system architecture

Physical connection

Interface

DC/DC conversion

Power & isolation

an animation of a blueprint with a pen drawing out architecture
Ian illustration of a checklist

IEEE standards of PoE



Type 1

Type 2

Type 3

Type 4
Name PoE PoE+ PoE ++, UPoE High-Power PoE
Standard 802.3af or 2 pair PoE 802.3at or PoE+ 802.3bt or PoE++/UPoE 802.3bt or high-power PoE
Port Power up to 15W includes PD class 0 up to 3 up to 30W includes PD class 4 up to 60W includes PD class 5 to 6 up to 100W includes PD class 7 to 8

Type 1
Name PoE
Standard 802.3af or 2 pair PoE
Port Power up to 15W includes PD class 0 up to 3


Type 2
Name PoE+
Standard 802.3at or PoE+
Port Power up to 30W includes PD class 4


Type 3
Name PoE ++, UPoE
Standard 802.3bt or PoE++/UPoE
Port Power up to 60W includes PD class 5 to 6


Type 4
Name High-Power PoE
Standard 802.3bt or high-power PoE
Port Power up to 100W includes PD class 7 to 8

Featured products

ON Semiconductor NCP1095 & NCP1096 High Power PoE-PD Controllers

NCP1095 & NCP1096 High
Power PoE-PD Controllers

Learn More
ON Semiconductor Connected Lighting Platform

Connected Lighting Platform

Learn More

Applications for key components

Tech Chat: Connected Lighting for Smart Homes and Buildings

an animation of a lightbulb lighting up

Connected Lighting

NCP1095/96 Integrated High-Power IEEE 802.3bt PoE-PD Controllers

an animation of a phone with sound waves scrolling in

15W IP Phones

NCP1090/91/92 Integrated IEEE 802.3af PoE-PD Interface Controllers

an animation of a security camera turning

30W – PTZ Camera

NCP1081/83 Integrated High-Power PoE-PD and 40W DC/DC Controller

an animation of two hands moving on an electronic device

Management Devices

NCP1095/96 Integrated High-Power IEEE 802.3bt PoE-PD Controllers
