Analog Devices / Maxim Integrated MAXREFDES130# 楼宇自动化扩展板
Maxim Integrated MAXREFDES130# 楼宇自动化扩展板采用 Arduino® 外形尺寸，与 ARM® mbed™ 和 Arduino 平台兼容。 该扩展板提供了用于原型设计的完整参考，包括八路 0-10VDC 模拟输出、一路 4-20mA 输出、一路 4-20mA 输入、八个非锁存继电器、三个锁存继电器、一个 RTC 及 1-Wire® 主器件。 MAXREFDES130# 可与一个或多个 MAXREFDES131#、1-Wire®、 Panasonic Grid-Eye® 传感器配合使用，打造完整的楼宇自动化解决方案。
The MAXREFDES130# features a 1-Wire® master bus for use with MAXREFDES131#, the 1-Wire® Panasonic Grid-Eye® Sensor for gesture sensing feedback to the platform. The MAXREFDES130# works well with one or more of the MAXREFDES131# to make a complete building automation solution. In addition, non-latching and latching relays allow for control of multiple power lines and temperatures, saving energy and ensuring a comfortable climate.
特性
- Analog IO
- Eight 0-10VDC outputs
- One 4-20mA Output
- One 4-20mA Input
- Arduino compatible
- ARM mbed compatible
- AC load switching
- Latching relays for thermostat control
- RTC
- Accelerated development time
- Flexible analog for multiple configurations
- Ease of use
应用
- Building automation
- IoT
- Animatronics
- Holiday displays
视频
Block Diagram
Related Products
Panasonic Grid-EYE®红外阵列传感器
64个8x8网格形式的热电堆元件，通过红外辐射检测绝对温度。
