Infineon Technologies OptiMOS™ 6功率MOSFET

另外，该器件具有更高的品质因数（FOM - R_DS(on) x Q_g和Q_gd），可让设计人员提高效率并降低系统成本。OptiMOS 6保持了输出更高功率的优势，其中R_DS(on) 损耗显著降低，从而在整个工作范围内进一步提高了性能。

40V功率MOSFET

Infineon Technologies OptiMOS™ 6 40V功率MOSFET经过优化，适用于各种应用和电路，包括服务器、台式电脑、无线充电器、快速充电器和ORing电路中开关模式电源 (SMPS) 的同步整流。在SMPS应用中，OptiMOS 6是在各种输出功率下优化效率的完美解决方案，且无需在低负载和高负载条件之间进行权衡。

OptiMOS 6 40V功率MOSFET有两种不同封装可供选择，一种是SuperSO8 - 5mm x 6mm，R_DS(on) 范围0.7mΩ至5.9mΩ，另一种是PQFN 3.3mm x 3.3mm，R_DS(on) 范围为1.8mΩ至6.3mΩ。

查看产品列表

80V Power MOSFETs

The OptiMOS™ 6 80V Power MOSFETs set industry benchmark performance with a wide portfolio offering, including PQFN 3.3mm x 3.3mm, SuperSO8, PQFN 5mm x 6mm Dual-Side Cooling, and PQFN 3.3mm x 3.3mm Source-Down. The 80V family is ideal for high switching frequency applications such as telecom, servers, and solar. The performance improvements of OptiMOS™ 6 80V also demonstrate benefits in battery management systems (BMS).

View Product List

100V Power MOSFETs

The OptiMOS™ 6 power MOSFET 100V family targets applications such as switch-mode power supply (SMPS), solar, power tools, and battery management systems. The enhanced performance yields efficiency improvement, allowing easier thermal design and less paralleling, reducing system costs.

View Product List

120V Power MOSFETs

Infineon Technologies OptiMOS™ 6 120V Power MOSFET family is suitable for hard- and soft-switching applications at high- and low-switching frequencies. These MOSFETs are available in both normal and logic levels. These devices can be used in various applications such as industrial power supplies, solar, power chargers, low-voltage drives, and power tools.

View Product List

135V POWER MOSFETS

Infineon OptiMOS 6 135V Power MOSFET targets high-power motor-drive applications such as LEVs, e-forklifts, power and gardening tools, and UPS, which predominantly use 72V and 84V batteries. This product family effectively bridges the gap between 120V and 150V MOSFETs and provides high performance with the lowest R_ds(on), enabling efficient power handling and reduced power dissipation.

View Product List

150V Power MOSFETs

Infineon Technologies OptiMOS™ 6 150V Power MOSFETs feature industry-leading low R_DS(on), improved switching performance, and excellent EMI behavior, which contribute to unparalleled efficiency, power density, and reliability. Applications include Light Electric Vehicles (LEV), motor control, power tools, energy storage systems, power conversion, industrial power supplies, server Power Supply Units (PSUs), telecommunication infrastructures, and photovoltaic applications.

View Product List

200V Power MOSFETs

Infineon Technologies OptiMOS™ 6 200V Power MOSFETs are N-channel MOSFETs available in PG-TO263-3, PG-TO220-3, and PG-HDSOP-16 packages. These MOSFETs feature excellent gate charge x R_DS(on) product (FOM), very low reverse recovery charge (Qrr), low on‑resistance R_DS(on), and improved capacitance linearity. The 200V variants address the need for high power density, high efficiency, and high reliability. Conduction and switching losses can be reduced without compromising EMI. The OptiMOS™ 6 200V MOSFETs are ideal for paralleling.

View Product List
