STMicroelectronics STM32MP1微处理器系列

STMicroelectronics STM32MP1微处理器系列是一系列支持轻松开发各种应用的器件。STM32MP1系列基于异构单核或双核Arm® Cortex®-A7和Cortex-M4内核架构。该系列支持多种灵活的应用。Cortex-A7内核可访问开源操作系统 (Linux/Android)。Cortex-M4内核采用STM32 MCU生态系统。

STM32MP13x is an STM32 Arm Cortex-A class microprocessor running at 650MHz and up to 1GHz. The STM32MP13x has additional features versus the STM32MP15x, including enhanced security capabilities and dual Ethernet.

The STM32MP13x MPUs offer an easier experience, reducing the time and cost of development thanks to a strong ecosystem for more security and longer battery life. The security level on the STM32MP13x has been significantly enhanced to protect data in any application, especially with connected devices to the cloud.

STM32MP13 comes in 3 different product lines
• STM32MP131 line
• STM32MP133 line with dual Ethernet and CAN FD
• STM32MP135 line with dual Ethernet, CAN FD, display, and camera.
All three lines have optional security features and enhanced CPU frequencies (i.e., up to 1GHz).

The STM32MP135 and the existing STM32MP1 Series can be combined with a dedicated Power Management IC (PMIC) designed by GPA ST's division. As an MPU, ST has an important ecosystem with software tools, hardware tools, strong partners, and a full, mainlined open-source Linux solution.

特性

内核
- Arm Cortex-A7双核，最高800MHz
- 32kB+32kB I/D L1缓存
- 256kB L2缓存
- 209MHz Arm Cortex-M4内核
外部存储器支持
- DDR 3、 DDR3L、 LPDDR 2、 LPDDR 3
- SLC NAND、SPI NAND
- eMMC、SD卡、Quad-SPI NOR
内部存储器
- 256KB系统RAM
- 384kB MCU系统RAM
- 64kB MCU保留RAM
模拟
- 2x 16位ADC
- 2x 12位DAC
